Description
Kit Includes:
- Cover Assembly
- Locking Ring
- Electronic Module
- Cover Rest Plate
- Solenoid
- Flex Tube Diaphragm
Quiet, Exposed, Sloan Solis Single Flush, Solar Powered, Sensor Activated Closet Flushometer Retrofit Conversion Kit for Sloan Royal, Regal Pro and Regal Flushometers with the following features:
- Solar Powered. The sensor assembly is powered by a solar cell that will harvest power from artificial indoor light, either incandescent or fluorescent light, and use it as the energy source. The solar cell can provide approximately 100% power with 650 Illuminance (lux).
- Four (4) Size AA Battery Back-up Power Source
- “Low Battery” Flashing LED
- If the user is present for less than one minute and leaves the sensing zone or chooses the small override button, a reduced flush initiates (1.1 gpf/4.2 Lpf) eliminating liquid and paper waste, saving 1/2 gallon of water
- If the user is present for greater than one minute and leaves the zone or chooses the large override button, the full flush initiates (1.6 gpf/ 6.0 Lpf) eliminating solid waste and paper
- Reduces water volume by up to 30% when a reduced flush occurs
- PERMEX Synthetic Rubber Diaphragm with twin linear filtered bypass and vortex cleansing action
- Flex Tube Diaphragm designed for improved life and reduced maintenance
- ADA Compliant Sloan Solis Electronic Single Flush Solar Powered Infrared Sensor for automatic “No Hands” operation
- Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection
- Latching Solenoid Operator
- Engineered Metal Cover with replaceable Lens Window
- User friendly three (3) second Flush Delay
- Courtesy Flush Override Buttons
- Infrared Sensor Range Adjustment Screw
- CP Handle Cap
- Initial Set-up Range Indicator Light (first 10 minutes)
- Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation
- Installation Tools provided
- Diaphragm molded from PERMEX Rubber Compound for Chloramine resistance
- 100% of the energy used in manufacturing is offset with Renewable Energy Sources Wind Energy
