Description
- SHOWERHEAD: 8” Dia. CYCOLAC Yellow Plastic.
- FLOW CONTROL: Internal 20 GPM Regulator.
- VALVE: 1” NPTF Brass, Chrome-Plated. Full Flow Stay-Open Ball Valve.
- ACTIVATOR: Powder-Coated Yellow, Aluminum Triangular Pull Rod.
- INTERNAL STANCHION: 1” IPS Galvanized Steel Pipe
- INLET: 1” NPT male, Underground Supply, 33” bury.
- FINISH: DuraJade Painted Green Finish.
EYE/FACE WASH
- SPRAYHEADS: (2) Yellow ABS Plastic Spray Outlets with Flip Top Dust Covers.
- VALVE: 1/2” NPTF Brass, Chrome-Plated. Full Flow Stay-Open Ball Valve.
- ACTIVATOR: Stainless Steel Push Handle.
ELECTRIC
- HEATING TAPE: Self-Limiting Parallel Resistance Cable with Braided Metal Shield.
- THERMOSTAT: Preset, Hermetically Sealed Single Pole Contact Switch. Temperature Range 600 to 700 degrees F.
- INSULATION: Closed Cell Rubber Foam.
- PILOT LIGHT: .025 Watt Red Light with Push Test Button. Lights When Thermostat Closes and Heating Tape is Activated.
- JUNCTION BOX: NEMA 4X Water Tight, Dust Tight, and Corrosion-Resistant for Indoor or Outdoor Locations.
- POWER SUPPLY: 120 VAC, 60 Cycle, Single Phase
- ELECTRICAL CLASSIFICATION: Class 1 Division 2 Groups B,C,D.
- GROUND FAULT PROTECTION: Installation will require minimum 30 mA GFPD.
